Grant Fittings, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch industrial components, including 45° Long Radius (LR) Elbows and 45° Short Radius (SR) Elbows. With a strong emphasis on precision engineering, durability, and compliance with international standards, Grant Fittings delivers dependable and efficient piping solutions for a wide range of industrial applications. Their 45° LR and SR Elbows are expertly crafted to facilitate smooth directional changes in piping systems, ensuring optimal flow while maintaining structural integrity even under high pressures and temperatures. Committed to quality and consistency, Grant Fittings caters to engineers, fabricators, and industrial clients both locally and around the globe.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 45° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 45° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 45° Long Radius Elbow
The 45° Long Radius Elbows feature a center-to-end radius that is 1.5 times the pipe diameter, allowing for a gentle shift in flow direction that minimizes turbulence and pressure loss. These elbows are perfect for systems that require smooth fluid movement and reduced stress on the piping. On the other hand, the 45° Short Radius Elbows have a center-to-end radius equal to the pipe diameter, making them ideal for compact installations where space is at a premium. Both types are crafted from corrosion-resistant, high-strength materials, ensuring they are durable, mechanically stable, and built for long-term performance.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Grant Fittings is a leading supplier of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow in Manila, Philippines. We offer an extensive range of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow from Grant Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
45° Long Radius and 45° Short Radius Elbows offer distinct advantages depending on application needs. The Long Radius Elbow provides a gradual, smooth bend, ensuring minimal pressure loss and efficient flow, making it ideal for high-velocity systems. It is commonly used in larger piping setups. The Short Radius Elbow, on the other hand, is perfect for compact installations with limited space, offering quick directional changes. Both types are highly durable, corrosion-resistant, and made from strong materials like stainless steel, ensuring long-lasting performance in industries such as oil and gas, HVAC, and chemical processing.
Yes, custom sizes for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow are available at Grant Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@grantfittings.com.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
You’ll find 45° LR and SR Elbows commonly used in industries such as petrochemical, chemical processing, oil and gas, water treatment, and power generation. They are well-suited for pipelines, pumps, compressors, and process systems that need directional changes in piping. Their precise design guarantees efficient fluid flow, reduces turbulence, and helps maintain overall system performance. These fittings not only enhance operational reliability and safety but also contribute to the longevity of industrial piping systems that demand durable, high-performance elbow solutions.
