Grant Fittings is a reputable manufacturer and supplier located in Manila, Philippines, known for its top-notch Alloy Steel F1 Forged Fittings. With a strong focus on precision engineering and durability, Grant Fittings provides high-quality forged fittings that adhere to international standards for strength and reliability. Their products find applications across various sectors, including petrochemical, power generation, and oil & gas. With years of experience and a talented workforce, the company guarantees timely delivery, competitive pricing, and outstanding customer service. When it comes to reliable forged fittings in Manila, Grant Fittings is the go-to choice for Alloy Steel F1 components.
| Specifications | Alloy Steel |
|---|---|
| Size | 1/8” NB TO 48” NB. |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Type | Seamless / Welded / Fabricated |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
Alloy Steel Forged Fittings are primarily composed of carbon, manganese, phosphorus, sulfur, and silicon, with additional alloying elements such as chromium, molybdenum, nickel, and vanadium to enhance strength, toughness, and resistance to wear and corrosion. These fittings offer superior mechanical properties, including high tensile strength, typically ranging from 550 to 700 MPa, and excellent yield strength, often exceeding 400 MPa. They are designed to perform reliably in high-pressure, high-temperature environments, providing excellent impact resistance and durability, making them ideal for demanding applications in industries like oil, gas, and petrochemicals.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| Alloy Steel | 0.08 – 0.12 | 0.3 – 0.6 | 0.5 | 0.01 | 0.02 | 8.5 – 9.5 | 0.85 – 1.05 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| Alloy Steel | 415 | 585 | 20 |
Alloy Steel F1 Forged Fittings are primarily made up of chromium (Cr) and molybdenum (Mo), which give them exceptional strength, hardenability, and resistance to corrosion. The typical chemical makeup includes 0.10% carbon, 0.50–0.80% manganese, 0.44–0.65% molybdenum, and 0.50–0.80% chromium. These fittings boast impressive mechanical properties, featuring a tensile strength of about 415 MPa and a yield strength of 205 MPa, with an elongation of 22%. These characteristics make Alloy Steel F1 perfect for high-temperature and high-pressure applications, ensuring durability and resistance to stress-related damage.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel Forged Fittings from Grant Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Alloy Steel Forged Fittings offer numerous advantages, including exceptional strength and durability, making them ideal for high-pressure and high-temperature applications. The alloying elements, such as chromium, molybdenum, and nickel, enhance corrosion resistance and wear resistance, ensuring long-term performance even in harsh environments. These fittings are designed for superior impact toughness, reducing the risk of failure in critical systems. Their forged construction provides enhanced mechanical properties, offering leak-proof and secure connections. Alloy Steel Forged Fittings are perfect for industries like oil, gas, petrochemical, and power generation, providing reliable and cost-effective solutions.
Yes, custom sizes for Alloy Steel Forged Fittings are available at Grant Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@grantfittings.com
| NPS | Outside diameter D | 45° Long Rad Center to End B | 90° Long Rad Center to End A | 45° 3D Center to End B | 90° 3D Center to End A |
| 1/2 | 21.03 | 16 | 38 | ||
| 3/4 | 26.07 | 19 | 38 | 24 | 57 |
| 1 | 33.04 | 22 | 38 | 31 | 76 |
| 1¼ | 42.02 | 25 | 48 | 39 | 95 |
| 1½ | 48.03 | 29 | 57 | 47 | 114 |
| 2 | 60.03 | 35 | 76 | 63 | 152 |
| 2½ | 73 | 44 | 95 | 79 | 190 |
| 3 | 88.09 | 51 | 114 | 95 | 229 |
| 3½ | 101.06 | 57 | 133 | 111 | 267 |
| 4 | 114.03 | 64 | 152 | 127 | 305 |
| 5 | 141.03 | 79 | 190 | 157 | 381 |
| 6 | 168.03 | 95 | 229 | 189 | 457 |
| 8 | 219.01 | 127 | 305 | 252 | 610 |
| 10 | 273 | 159 | 381 | 316 | 762 |
| 12 | 323.08 | 190 | 457 | 378 | 914 |
| 14 | 355.06 | 222 | 533 | 441 | 1067 |
| 16 | 406.04 | 254 | 610 | 505 | 1219 |
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Grant Fittings’ Alloy Steel F1 Forged Fittings are widely utilized in industries where high strength and resistance to heat and pressure are essential. This includes oil and gas refineries, power plants, chemical processing facilities, and marine engineering systems. The fittings are perfect for connecting pipelines, valves, and equipment in high-temperature and corrosive settings. Thanks to their toughness and mechanical stability, they are the preferred choice for steam lines, heat exchangers, and pressure vessels. Their precise design guarantees leak-proof performance, making them ideal for high-pressure fluid and gas transmission systems in demanding industrial environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
