Hastelloy Pipe Fittings Manufacturer and Supplier In Manila, Philippines

Grant Fittings stands out as a reliable manufacturer and supplier of Hastelloy Pipe Fittings right in the heart of Manila, Philippines. We specialize in providing high-performance solutions tailored for industries that operate in tough, corrosive environments. Our extensive range of Hastelloy pipe fittings includes elbows, tees, reducers, stub ends, and caps, all crafted to deliver outstanding corrosion resistance and mechanical strength. Using top-quality materials like Hastelloy C22, C276, and X, our fittings are perfectly suited for applications in chemical processing, marine, power generation, and pharmaceuticals. At Grant Fittings, we ensure that every product adheres to international standards for quality, pressure integrity, and long-lasting durability.

Hastelloy Pipe Fittings Specification
Hastelloy Pipe Fittings Chemical Composition
Hastelloy Pipe Fittings Mechanical Properties
Equivalent Grades for Hastelloy Pipe Fittings
Largest Hastelloy Pipe Fittings Supplier in Manila, Philippines
Hastelloy Pipe Fittings Dimensions Standard
Why Choose Hastelloy Pipe Fittings from Grant Fittings?
Types of Hastelloy Pipe Fittings
Are Custom Sizes Available for Hastelloy Pipe Fittings?
Application Industry of Hastelloy Pipe Fittings

Hastelloy Buttweld Elbow In Philippines, ASTM B366 Hastelloy Alloy Pipe Fittings United kingdom, Hastelloy Stub End Manila, Hastelloy Reducing Tee Cebu City, Hastelloy Pipe Fittings in Davao City, Hastelloy Buttweld Fittings Puerto Princesa, ASME SB366 Hastelloy® Alloy Pipe Cap Baguio, Philippines.

Hastelloy Pipe Fittings Specification

Specification : ASTM B366 / ASME SB366

Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings

ASME B16.25 : Buttwelding Ends

ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends

MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)

Seamless Butt Weld Fitting Size : 1/2″ – 10″

Welded Butt Weld Fittings Size : 1/2″ – 48″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Type : Seamless / Welded / Fabricated.

Our Hastelloy Pipe Fittings are made from nickel-molybdenum and nickel-chromium-molybdenum alloys, which are renowned for their exceptional resistance to both oxidizing and reducing agents. These fittings are designed to endure harsh conditions, including acidic environments, high temperatures, and the risk of pitting or stress corrosion cracking. With excellent weldability and formability, our Hastelloy fittings guarantee reliable performance in both seamless and welded piping systems. Each fitting is subjected to thorough testing, including hydrostatic pressure tests, Positive Material Identification (PMI), and dimensional inspections, ensuring maximum reliability for critical operations.

Hastelloy Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 – 16.50	4.00 – 7.00	15.00 – 17.00	0.04 max

Hastelloy Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790	Psi – 52,000 , MPa – 355	40 %

Equivalent Grades for Hastelloy Pipe Fittings

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–
Hastelloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760

Hastelloy 90 deg Elbow In Philippines, Hastelloy 45 deg. Elbow United kingdom, Hastelloy Reducer, ANSI B16.9 Hastelloy Buttweld Pipe Fittings Suppliers in Manila, Hastelloy Seamless Pipe Fittings Manufacturers Cebu City, Hastelloy Pipe Bend in Davao City, Hastelloy Pipe Fittings Price List in Puerto Princesa, Hastelloy Pipe Elbow Suppliers Baguio, Hastelloy Buttweld Cross In Philippines, Hastelloy Welded Pipe Fittings Exporter in Manila, Philippines.

Largest Hastelloy Pipe Fittings Supplier in Manila, Philippines

Across the Philippines, industries trust Hastelloy Pipe Fittings from Grant Fittings for systems where corrosion failure simply isn’t an option. Our fittings are frequently utilized in reactors, scrubbers, heat exchangers, and pipelines that handle aggressive media. Known for our precision manufacturing, prompt delivery, and dedicated technical support, Grant Fittings is committed to providing customized solutions that meet the rigorous demands of industrial clients seeking high-grade corrosion-resistant products.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy Pipe Fittings Dimensions Standard

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Reducers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Why Choose Hastelloy Pipe Fittings from Grant Fittings?

Hastelloy Pipe Fittings from Grant Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

wide range of Hastelloy pipe fittings in a variety of size In U, wall thicknesses, dimensions and tolerance to meet your project’s needs—including pipe fittings in dimension as per ASME/ANSI B16.9, ASME B16.25, ASME B16.28, ASME B16.49, MSS-SP-43 Fittings / weight & thickness of Hastelloy pipe fittings.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy pipe fittings offer numerous advantages, including outstanding corrosion resistance against harsh chemicals, oxidizing agents, and reducing environments. They excel in high-temperature applications and provide exceptional durability and strength, ensuring long-lasting performance. Hastelloy resists stress corrosion cracking, pitting, and crevice corrosion, making it ideal for demanding industries like chemical processing, marine engineering, and power generation. Their superior weldability and fabrication ease enable precise custom solutions. With a proven ability to withstand extreme conditions, Hastelloy pipe fittings are a reliable choice for critical applications requiring high performance and dependability.

Types of Hastelloy Pipe Fittings

Are Custom Sizes Available for Hastelloy Pipe Fittings?

Yes, custom sizes for Hastelloy Pipe Fittings are available at Grant Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@grantfittings.com.

Hastelloy Buttweld Elbow In Philippines, ASTM B366 Hastelloy Alloy Pipe Fittings United kingdom, Hastelloy Stub End Manila, Hastelloy Reducing Tee Cebu City, Hastelloy Pipe Fittings in Davao City, Hastelloy Buttweld Fittings Puerto Princesa, ASME SB366 Hastelloy® Alloy Pipe Cap Baguio, Philippines.

Application Industry of Hastelloy Pipe Fittings

Hastelloy pipe fittings are widely used in industries requiring superior corrosion resistance and durability. They are essential in chemical processing plants for handling aggressive chemicals and acids. In the marine industry, Hastelloy fittings provide resilience against seawater corrosion, while in power generation, they ensure reliability in high-temperature environments. These fittings are also employed in aerospace for critical components and in pharmaceuticals to maintain hygienic and contamination-free systems. Their versatility and strength make them ideal for challenging applications in both oxidizing and reducing conditions.
