Grant Fittings is a reliable manufacturer and supplier located in Manila, Philippines, known for its top-notch Alloy Steel F1 Forged Fittings. With a strong focus on precision engineering and durability, Grant Fittings provides high-quality forged fittings that adhere to international standards for strength and reliability. Their products find applications across various sectors, including petrochemical, power generation, and oil & gas. With years of experience and a talented team, the company guarantees timely delivery, competitive pricing, and outstanding customer service. When it comes to dependable forged fittings in Manila, Grant Fittings is the go-to choice for Alloy Steel F1 components.
| Specifications | ASTM A815/ ASME SA815 |
|---|---|
| Bending Radius | Radius=1 D, 2D, 3 D, 5D, 6D, 8 D, 10D |
| Size Range | Seamless Butt-Weld Fitting: From 1/2″ – 10″ Welded ButtWeld Fitting: From 1/2″ – 48″ |
| Dimension | ASME/ ANSI B16.9 | ASME B16.28 | MSS-SP-43 | BS1560 | BS4504 | BS10 |
| Size Ranges | ½” NB to 24″ NB in Schedule 10s, 40s, 80s, 160s, XXS. |
| Other Grades | Duplex 2205 Fittings, UNS S31803 Fittings, UNS S32205 Fittings |
| Types | Welded | Seamless | Fabricated |
| Process of Duplex Steel Fittings Manufacturer in india | Push, Press, Cast, Forge. |
| Thickness of Fitting | SCH10, SCH 20, SCH30, STD SCH40, SCH80, SCH60, XS, SCH100, SCH 120, SCH140, SCH 160, XXS available with NACE MR 01-75 |
Duplex Steel Pipe Fittings are composed of a dual-phase microstructure of austenite and ferrite, typically containing 22-25% chromium, 4-7% nickel, and 2-4% molybdenum, with nitrogen for added strength and corrosion resistance. These fittings offer excellent mechanical properties, including a tensile strength of 620-850 MPa, yield strength of 450-600 MPa, and elongation of about 25%. They exhibit high resistance to pitting, crevice corrosion, and stress corrosion cracking, making them durable in harsh environments. Their superior weldability and toughness make them ideal for industrial and marine applications.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S31803 / S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
Alloy Steel F1 Forged Fittings are primarily made up of chromium (Cr) and molybdenum (Mo), which give them exceptional strength, hardenability, and resistance to corrosion. The typical chemical makeup includes 0.10% carbon, 0.50–0.80% manganese, 0.44–0.65% molybdenum, and 0.50–0.80% chromium. These fittings boast impressive mechanical properties, featuring a tensile strength of about 415 MPa and a yield strength of 205 MPa, with an elongation of 22%. These characteristics make Alloy Steel F1 perfect for high-temperature and high-pressure applications, ensuring long-lasting performance and resilience against stress-related damage.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex 2205 | 1.4462 | S31803 / S32205 |
Duplex Steel Pipe Fittings from Grant Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Duplex Steel Pipe Fittings offer exceptional corrosion resistance, making them ideal for use in harsh environments such as marine and chemical industries. They combine high strength and durability, ensuring reliable performance under high-pressure and high-temperature conditions. These fittings resist stress corrosion cracking and have good weldability, simplifying installation and maintenance processes. Their cost-effectiveness, achieved through reduced material weight without compromising strength, adds significant value. Duplex Steel’s versatility also ensures excellent resistance to pitting and crevice corrosion, making it a reliable choice for diverse and challenging applications.
Yes, custom sizes for Duplex Steel Pipe Fittings are available at Grant Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@grantfittings.com.
Grant Fittings’ Alloy Steel F1 Forged Fittings are widely utilized in industries where high strength and resistance to heat and pressure are essential. This includes oil and gas refineries, power plants, chemical processing facilities, and marine engineering systems. The fittings are perfect for connecting pipelines, valves, and equipment in high-temperature and corrosive settings. Thanks to their toughness and mechanical stability, they are favored for use in steam lines, heat exchangers, and pressure vessels. Their precise design guarantees leak-proof performance, making them ideal for high-pressure fluid and gas transmission systems in demanding industrial environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
