Grant Fittings stands out as a trusted manufacturer and supplier of Monel Forged Fittings right in the heart of Manila, Philippines. With a focus on top-notch forged fittings, the company provides an extensive selection of products, including elbows, tees, reducers, couplings, and unions crafted from high-quality Monel alloys. Renowned for their remarkable corrosion resistance and mechanical strength, Monel forged fittings are perfect for tough environments like marine, chemical processing, and the oil and gas sectors. Grant Fittings guarantees that all their fittings meet international standards, delivering durable and dependable solutions to clients throughout the Philippines and beyond.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
The Monel Forged Fittings from Grant Fittings are primarily made of nickel and copper, offering outstanding resistance to seawater, acids, and alkaline solutions. The forging process not only boosts their strength but also enhances their toughness, making them ideal for high-pressure and high-temperature applications. These fittings are also known for their exceptional resistance to stress corrosion cracking and erosion, ensuring they perform reliably in challenging conditions. Each fitting goes through strict quality control and testing to ensure they meet performance and safety standards in critical piping systems.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Grant Fittings is a leading supplier of Monel Forged Fittings in Manila, Philippines. We offer an extensive range of Monel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Choose Monel Forged Fittings from Grant Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Grant Fittings’ Monel Forged Fittings are widely utilized in industries that demand durability and corrosion resistance, such as offshore oil rigs, chemical plants, desalination facilities, and marine engineering. Their ability to endure extreme environments makes them a go-to choice for piping systems that come into contact with harsh chemicals and saltwater. Grant Fittings is committed to providing reliable Monel forged fittings across the Philippines, helping clients maintain efficient, safe, and long-lasting industrial operations.
Yes, custom sizes for Monel Forged Fittings are available at Grant Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@grantfittings.com
Monel Forged Fittings are widely used in industries requiring high strength and resistance to harsh environments. In marine applications, they are essential for seawater systems, pipelines, and pumps due to their resistance to corrosion and seawater. In chemical processing, Monel fittings are used in handling aggressive chemicals and high-temperature processes. They are also used in offshore oil and gas platforms, power generation plants, and aerospace industries, where durability, reliability, and corrosion resistance are critical. Monel Forged Fittings ensure long-lasting, high-performance solutions for demanding applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
